Common properties

Most elements share the same core properties. Element-specific properties are covered on each element page.

Finding a property

The properties sidebar has a search box (Search in property list) — type part of a property name to filter. Every field also has a help icon: hover it for a short explanation with an example.

How the sidebar is organised

Properties are grouped into sections. Only sections relevant to the selected element appear:

Section	What it holds
Identity	Name, label, and basic identifiers
Content	Visible texts, titles, placeholders, and content fields
Input	Input modes, autocomplete, and user input UX
Formatting	Masks, locale, and value formatting settings
Primary source	Data source binding and response paths
Request	Request params, lazy load, and backend request settings
Search	Quick or detailed search and their extra settings
Saved filters	Saved filters data source and payload schema
Options schema	Option lists, filtering, and selection modes
Selection	Table selection and selected item configuration
Details	Expanded rows, details panel, and nested views
Pagination	Paginator and footer control
Header controls	Header bar, export, and search controls
Columns schema	Main and expanded table columns
Trigger button	Button that opens a dialog or another action
State	Hidden, disabled, and readonly states
Limits	Min/max, lengths, counts, and other restrictions
Deletion	Delete flow and confirm settings
Validation	Required, validators, and strict options
Visibility logic	Visible-if and open conditions
Interaction logic	Disable, require, and readonly conditions
Value logic	Expression, default value, and reset conditions
Execution modes	Logic and validation execution mode settings
Actions	Events and action collections
Layout	Width, padding, orientation, gap, and overall layout
Surface	Borders, backgrounds, shadows, and page or panel surfaces
Appearance	Variants, colors, icons, and visual accents
Advanced	Rare or specialized properties

Identity & content

Property	What it does
Name (code)	Unique element code in the JSON structure. The element's value is stored under this key, and logic, data paths, and other elements reference it as {name}. Change with care. Example: el1 or personFirstName.
Label	The main caption visible to the user. Keep it clear in business terms.
Field help tooltip	Help text shown next to the label as a tooltip — for explanations that should be available on demand but not always visible.
Description	Help text below the label — for longer explanations that should always be visible at runtime.
Placeholder text	Text shown while the field is empty. Use as an example or short hint, not as the only explanation.
Title / Subtitle	Main heading text and secondary text for elements with their own header (cards, page titles, panels).
Text	Main text for content-style elements (button caption, badge text…).
Icon	Material Symbol or registered SVG icon code — a visual accent or a shorter action representation.
Type	Switches the element to a closely related type without recreating it (e.g. text → number), preserving shared properties.

State

Property	What it does
Hidden	Element is completely hidden from the user (its value and logic still exist).
Initially visible	Whether the element is shown immediately when the form opens, before logic or user actions apply.
Disabled	Field is inactive; the user cannot change it.
Read only	Value is displayed but cannot be edited.
Inherit parent state	Element follows the read-only/disabled state of its parent container or page. Turn off to unlock one child inside a locked container.
Ignore parent state	Legacy compatibility field — use Inherit parent state instead.
Status	Legacy compatibility field — for new elements use the Read only checkbox.

Static Disabled/Hidden are fixed choices. For state that depends on other fields, use the logic conditions below.

Limits

Property	What it does
Min / Max length	Character limits on text inputs. Min length means the field counts as filled/valid only from that many characters.
Min / Max value	Numeric or date/time boundaries (numbers, sliders, date pickers).
Pattern	Extra RegExp check on text values — for strict formats such as codes, registration numbers, identifiers.
Max rows	Row limit for dynamic tables/panels — the add button disables at the limit.
Max files / Max file size (MB)	Upload limits on file elements.

Validation

Property	What it does
Required	Value must be filled before submit. Pair with a clear message.
Required field message	Error text shown when a required field is empty. Localise it on multilingual forms.
Validators	A list of extra rules: built-in (min/max, length, pattern, email) or a custom condition with its own error message. Each validator has Type, Value, Error message, Condition (error when true), and Apply if (optional guard). See Validation.
Strict options	On choice elements: validates that the current value(s) still exist among the available options.

Logic

All conditions are expressions entered via Edit code — see Expressions basics.

Property	Expects	What it does
Visible if	true/false expression	Shows the element only while true. Example: {el1} == "yes"
Disable if	true/false expression	Disables while true. Example: {el1} != "yes"
Require if	true/false expression	Makes required while true. Example: {el2} == 1
Read only if	true/false expression	Locks editing while true. Example: {status} == "locked"
Reset if	true/false expression	Resets the value to Default value when the condition becomes true (fires on the transition).
Expression	any value	Calculates the element's value from other fields. Example: {price} * {quantity}
Default value	static value	Initial value on load and the value restored by Reset if.

Details: Conditional logic and Calculated values.

Actions

Property	What it does
Events	The action list: click → navigate, click → dataSource, change → setValue, click → toast… Every field of the action editor is documented in Events & actions.

Input & formatting (typed inputs)

Property	What it does
Autocomplete	HTML autocomplete attribute — lets the browser fill standard data. Example: given-name, email, street-address.
Input mode	HTML inputmode hint — mobile browsers show a matching keyboard. Options: text, email, numeric, decimal, search, tel, url, browser default.
Spellcheck	Keep or disable the browser spell-checker on text fields.
Input mask	Mask template. Built-ins: date, date time, time, digits, phone, international phone, personal code — or custom.
Mask pattern	The custom mask: # digit, A letter, * letter or digit. Example: ####-##-## or +1 ##########.

Design

Property	What it does
Width	Field width in desktop/base mode — %, px, or other CSS units. Example: 100% or 320px.
Tablet width	Width for tablet. Empty = falls back to the base width.
Mobile width	Width for mobile. Empty = falls back to tablet width, then base width.
Fit content	Shrink to content width instead of filling the row.
Background color, padding, radius, shadow, border	Available on visual/surface elements like panels, buttons, badges — see the element pages and Layout.

Data

Select-style elements and data views have a Data source binding (section Primary source): which source to load, which response fields become option value/label, request parameters, and refresh rules. Dependent fields are supported through the parameter map and Listen fields (refresh paths). Every field of that editor is documented in Data sources.
