Content & media
Presentational elements. They display information and add nothing to the form data.
This lesson covers buttons, message cards and the other elements that only show something:
Chapters (6)
Rich text (richText / richTextViewer)
Formatted text written in a WYSIWYG editor: headings, bold, lists, links, images, video. Use it for instructions, section intros, and legal text. The viewer variant renders content read-only at runtime.
| Property | What it does |
|---|---|
| HTML content | The content itself. Opens in a dialog you can move and resize, with a Text editor and an HTML tab. Placeholders render live values: {{firstName}} or {user.name}. See Dynamic text & templates. |
| HTML source path | Viewer only: take the markup from a data path or a source response instead of the property. |
| Visible tools | Which toolbar buttons the editor offers: bold, italic, underline, strikethrough, headings, font family, text size, colors, highlight, alignment, lists, quote, inline code, link, image, horizontal rule, line spacing, sub/superscript, undo/redo, clear formatting. |
The viewer resolves placeholders too, so markup arriving from data can carry {el2}, {variable1}, or {row.column3} inside a table row.
Content written in a Custom HTML element renders the same way here. Both elements read the same <style> block and the same classes, so text colors, fonts, sizes, and alignment survive a copy from one to the other.
Custom HTML (customHtml / htmlSnippet)
Raw HTML for layouts the rich text editor can't produce. HTML is sanitised at runtime, so scripts are stripped.
Both fields are in the General category, under the name. Edit content opens the markup in the code editor.
| Property | What it does |
|---|---|
| HTML template (inline) | Supports @if/@for blocks, {{...}} placeholders, and click bindings: (click)="action('Open dialog')" or (click)="loadData(id)". |
| HTML template ref | Reference to a Templates-tab template. Wins over the inline HTML. Shown when the Templates plugin is installed. |
Image (image)
| Property | What it does |
|---|---|
| Source URL | Image address (can contain {tokens}). |
| Local file | Pick an image from your computer. It is stored as a data URL and takes priority over the URL. |
| Alt text | Accessibility text, also shown when the image fails to load. |
| Fit | How the image fills its box: cover, contain, fill, none (CSS object-fit). |
| Object position | Which part stays visible with cover (CSS object-position). |
| Image height / Radius | Sizing and corner rounding. |
| Loading mode | eager or lazy. |
| Link URL + Open in new tab | Make the image clickable. |
| Caption + Caption alignment | Short context or source line under the image. |
Video (video)
Embedded video player.
| Property | What it does |
|---|---|
| Provider | native, youtube, or vimeo. Determines which extra settings apply. |
| Source URL | Video or YouTube/Vimeo URL. Insecure or missing URLs are blocked. |
| Autoplay | Browsers usually require Muted together with autoplay. |
| Muted / Loop / Controls | Playback basics; disable controls only with your own UI. |
| Plays inline | Play inline instead of fullscreen on mobile (important on iOS). |
| Poster | Preview image before playback. |
| Privacy mode | Reduced-tracking embed where the provider supports it. |
| Aspect ratio | Keeps a constant width-to-height ratio. |
IFrame (iframe)
Embeds an external page: maps, dashboards, documents. The URL can include field tokens: https://maps.example.com?q={city}. Insecure sources are blocked.
| Property | What it does |
|---|---|
| Source URL | The embedded address. |
| Frame height | Base height for the frame. |
| Allow | The iframe allow attribute. Grant only what's needed (fullscreen; clipboard-read). |
| Allow fullscreen | Lets the embedded content go fullscreen. |
| Sandbox | The sandbox attribute. Restrict carefully; an overly strict sandbox can break the content. |
| Referrer policy | Only when the embedded host requires specific behaviour. |
Icon (icon)
A single icon by name, for decoration or visual anchors.
| Property | What it does |
|---|---|
| Icon | Material Symbol code or a registered SVG icon name. Developers can register extra SVG icons; ask which names your project has. |
| Icon color / Icon size | Visual tuning. |
Avatar (avatar)
A round profile image with fallback initials. Configure the image URL, the name text, size, and shape; an optional Link URL makes it clickable.
Page title (pageTitle)
A styled heading for the top of a page, larger than a label.
| Property | What it does |
|---|---|
| Title / Subtitle | Heading and support text. |
| Level | Heading level (h1, h2…) for consistent document structure. |
| Show divider | A separator line under the title block. |
| Title underline (+ color, width) | Accent line under the title text. |
Breadcrumbs (breadcrumbs)
A navigation trail (Clients / Jonas / Edit). Items can be static or built from the route and data.
| Property | What it does |
|---|---|
| Show home + Home label + Home URL | The leading home link. |
| Separator | The divider between items. |
| Include current page | Whether the current page appears as the last crumb. |
| Route label data key | Take item labels from a data-source object. |
| Use path fallback | Fall back to the URL segment when no label is found. |
Chart (chart)
Renders a chart from a data source or expression-provided data.
| Property | What it does |
|---|---|
| Chart type | Bar, Horizontal bar, Line, Area, Pie, Donut. See below for which to pick. |
| Data source / Data path | Where the items come from; point the path at the list inside the response (stats.points). |
| Points | Items typed in directly, instead of a source. |
| Label key / Value key | Which field of each item is its name and which its number (default label and value). |
| Merge items with the same label | Two items called Audi become one bar with their sum. On by default. |
| Chart height | Height of the plot area in pixels. |
| Show legend / Legend layout | Pie and donut only: the legend lists every slice with its value and share, as a list beside the chart or inline under it. |
Which type to pick:
- Bar compares a handful of categories; Horizontal bar is better when the names are long or there are many of them.
- Line and Area show change over time.
- Pie and Donut show parts of a whole. They work for up to six slices; anything beyond that is folded into one Other slice. A donut shows the total in its centre, and the hovered slice's value and share.
A bar, line or area chart is one series, so it is drawn in one colour and needs no legend: the title says what it shows. Pie and donut slices get distinct colours from a palette picked so that neighbouring slices stay apart for colour blind readers too.
Hovering a bar, point or slice shows its value. The chart can also be used with the keyboard: tab to it, move with the arrow keys, Enter runs the click action.
Click actions. Add actions under Events with the Click trigger and they run when someone clicks a bar, a point, a slice or a legend row. The clicked item is available as {item.label} and {item.value} (and {index}), so a click can, for example, set a filter field to {item.label} or open a detail dialog. Only a chart with a click action shows the hand cursor and the "Click to select" hint.
Charts refresh when their data source reloads. Combine that with React to change to make dashboards live.
